Pipedata - Piping dimension & weight info

Discover essential piping dimensions & weights effortlessly, ensuring accuracy for all your engineering projects.

Pipedata
  • 1598 Version
  • 3.2 Score
  • 433K+ Downloads
  • Free License
  • 3+ Content Rating
Download Android APK (7.03 MB)
Old Versions
Pipedata Pipedata Pipedata Pipedata Pipedata Pipedata Pipedata Pipedata
CONS

Limited flange details available

Missing weight details in the app

Issues with app accessibility (black screen)

High cost for pro features

Requires installation of additional apps for full functionality

Incomplete information on fittings (e.g., concentric reducer)

Font size too small, hard to read

Lacks tolerance variations and acceptance criteria

Pipedata provides detailed dimensional and weight metrics for 72 widely used ASME piping components, all presented in a user-friendly interface for quick and easy access. The Pipedata brand has been established since 1996, originally associated with Pipedata-Pro. Since its inception, it has achieved international recognition within the piping sector, gaining favor among large enterprises and individual users who value its precision and current relevant data.

In accordance with the most recent ASME piping dimensional guidelines, it offers information in Metric, U.S. Customary Units, and Inch Fractions along with NPS and DN pipe sizes. It includes verified weights for valves, flanges, pipes, and all other parts of the piping system.

DATA SUMMARY

Pipes adhere to ASME B36.10M/19M - 2004 standards.

Weld Neck Flange, conforms to ASME B16.5-2013.

Slip On Flange, per ASME B16.5-2013.

Blind Flange, compliant with ASME B16.5-2013.

Threaded Flange, ASME B16.5-2013 standards.

Socket Welded Flange, following ASME B16.5-2013 specifications.

Lapped Flange, as per ASME B16.5-2013.

Long Welding Neck Flange, adheres to ASME B16.5-2013.

Butt Welded 45-degree Elbow, per ASME B16.9-2007.

Butt Welded 90-degree Long Radius Elbow, abiding by ASME B16.9-2007.

Butt Welded 180-degree Long Radius Return, following ASME B16.9-2007.

Butt Welded 90-degree Short Radius Elbow, according to ASME B16.9-2007.

Butt Welded 180-degree Short Radius Return, adhering to ASME B16.9-2007.

Butt Welded Equal Tee, as specified by ASME B16.9-2007.

Butt Welded Reducing Tee, consistent with ASME B16.9-2007.

Butt Welded Cap, according to ASME B16.9-2007.

Butt Welded Concentric Reducer, per ASME B16.9-2007.

Butt Welded Eccentric Reducer, in line with ASME B16.9-2007.

Butt Welded Lap Joint Stub End, complying with ASME B16.9-2007.

Threaded 90-degree Elbow, under ASME B16.11-2011 regulations.

Threaded Tee, as per ASME B16.11-2011.

Threaded Cross, complying with ASME B16.11-2011.

Threaded 45-degree Elbow, according to ASME B16.11-2011.

Threaded 90-degree Street Elbow, following ASME B16.11-2011.

Threaded Coupling, aligned with ASME B16.11-2011.

Threaded Half Coupling, based on ASME B16.11-2011.

Threaded Cap, according to ASME B16.11-2011.

Threaded Square Head Plug, ASME B16.11-2011.

Threaded Hex Head Plug, ASME B16.11-2011.

Threaded Round Head Plug, ASME B16.11-2011.

Threaded Hex Head Bushing, ASME B16.11-2011.

Threaded Flush Bushing, ASME B16.11-2011.

Socket Welded 90-degree Elbow, according to ASME B16.11-2011.

Socket Welded 45-degree Elbow, as defined by ASME B16.11-2011.

Socket Welded Tee, under ASME B16.11-2011 specifications.

Socket Welded Cross, following ASME B16.11-2011.

Socket Welded Coupling, aligning with ASME B16.11-2011.

Socket Welded Half Coupling, as per ASME B16.11-2011.

Socket Welded Cap, according to ASME B16.11-2011.

Socket Welded Reducing Coupling, classified as ASME Unadopted.

Socket Welded Welding Boss, categorized as ASME Unadopted.

Socket Welded Reducing Insert Type 1, regarded as ASME Unadopted.

Socket Welded Reducing Insert Type 2, designated as ASME Unadopted.

Socket Welded Reducing Insert Type 3, classified under ASME Unadopted.

Socket Welded Union, recognized as ASME Unadopted.

Socket Details, conforming to ASME B16.11-2011.

Non-Metallic Flat Ring for ASME B16.5 Flanges, ASME B16.21-2011.

Non-Metallic Flat Ring for ASME B16.47 Series A Flanges, ASME B16.21-2011.

Non-Metallic Flat Ring for ASME B16.47 Series B Flanges, ASME B16.21-2011.

Spiral Wound Gasket for ASME B16.5 Flanges, ASME B16.20-2012.

Spiral Wound Gasket for ASME B16.47 Series A Flanges, ASME B16.20-2012.

Spiral Wound Gasket for ASME B16.47 Series B Flanges, ASME B16.20-2012.

RTJ Soft Iron Ring Type R, ASME B16.20-2012.

RTJ Soft Iron Ring RX, according to ASME B16.20-2012.

RTJ Soft Iron Ring BX, compliant with ASME B16.20-2012.

Flanged Gate Valve, regulated by ASME B16.10-2009.

Flanged Globe Valve, as stated in ASME B16.10-2009.

Flanged Ball Valve, conforming to ASME B16.10-2009.

Flanged Control Valve, related to ASME B16.10-2009.

Flanged Swing Check Valve, governed by ASME B16.10-2009.

Flanged Wafer Check Valve, as per API 594.

Wafer Type Butterfly Valves, according to ASME B16.10-2009.

Lug Type Butterfly Valves, ASME B16.10-2009.

Butt Welded Gate Valve, ASME B16.10-2009...

- and much more available for exploration.
